Maintain optimum water temperature by lowering the water temperature of your tank
Memory Recall - thermostat returns to last set temperature in the event of power outage
High BTU rating (heat removal) - Uniquely designed Heat Exchanger provides 25% BTU per watt advantage over other chillers
High quality, durable, reliable and efficient
Powerful and compact design
Quickly lowers and maintains desired water temperature and improves water quality in your tank
Corrosion resistant Titanium Heat Exchanger cools efficiently
Digital LED display for simplified functional control
Anti-Freezing System protects heat exchanger from freezing
Powerful compressor uses DuPont® R134a ozone friendly cooling agent
Efficient and reliable compressor saves money by using less electricity
Automatic power surge shut-off control with last set temperature recall system, returns chiller to last set temperature in case of a power surge or power outage
High BTU (heat removal) rating, heavy duty condenser effortlessly releases collected heat from water
Easy to remove front condenser cover for easy cleaning
Quick easy set-up & cleaning maintenance
|
Tank size up to:
|
50 Gallons
|
|
Dimensions
|
13.5"L x 8.5"W x 13"H
|
|
Rating
|
1/13HP
|
|
Ideal tank size
|
40 Gallons
|
|
Inlet/Outlet
|
1/2" & 1/2"
|
|
Chilling Capability
|
50 Gal:10ºF /30 Gal:20ºF
|
|
Rated Voltage
|
110-120V
|
|
Working Current
|
1.6A
|
|
Frequency
|
60 Hz
|
|
Refrigerant
|
134a
|
|
BTU
|
800
|
|
Recommended Pump Flow (GPH)
|
50-260 GPH
|
|
Tank size up to:
|
80 Gallons
|
|
Dimensions
|
14.5"L x 10"W x 14.5"H
|
|
Rating
|
1/10HP
|
|
Ideal tank size
|
60 Gallons
|
|
Inlet/Outlet
|
1/2" & 5/8"
|
|
Chilling Capability
|
60 Gal:20ºF / 80 Gal:10ºF
|
|
Rated Voltage
|
110-120V
|
|
Working Current
|
2.2A
|
|
Frequency
|
60 Hz
|
|
Refrigerant
|
R134a
|
|
BTU
|
1485
|
|
Suggested Pump Size
|
158-581 GPH
|
|
Tank size up to:
|
170 Gallons
|
|
Dimensions
|
17.5"L x 13"W x 17.5"H
|
|
Rating
|
1/2HP
|
|
Ideal tank size
|
150 Gallons
|
|
Inlet/Outlet
|
3/4" & 3/4"
|
|
Chilling Capability
|
100 Gal:30ºF / 170 Gal:10ºF
|
|
Rated Voltage
|
110-120V
|
|
Working Current
|
3.0A
|
|
Frequency
|
60 Hz
|
|
Refrigerant
|
R134a
|
|
BTU
|
3200
|
|
Suggested Pump Size
|
158-581 GPH
|
|
Tank size up to:
|
320 Gallons
|
|
Dimensions
|
19"L x 14"W x 19"H
|
|
Rating
|
1/2HP
|
|
Ideal tank size
|
250 Gallons
|
|
Inlet/Outlet
|
1" & 1"
|
|
Chilling Capability
|
200 Gal:30ºF / Gal:10ºF
|
|
Rated Voltage
|
110-120V
|
|
Working Current
|
4.4A
|
|
Frequency
|
60 Hz
|
|
Refrigerant
|
R134a
|
|
BTU
|
6800
|
|
Suggested Pump Size
|
158-581 GPH
|
|
Tank size up to:
|
700 Gallons
|
|
Dimensions
|
20.5"L x 14"W x 19"H
|
|
Rating
|
1HP
|
|
Ideal tank size
|
500 Gallons
|
|
Inlet/Outlet
|
1.25" & 1.25"
|
|
Chilling Capability
|
700 Gal:10ºF / 300 Gal:30ºF
|
|
Rated Voltage
|
110-120V
|
|
Working Current
|
9.6A
|
|
Frequency
|
60 Hz
|
|
Refrigerant
|
R22
|
|
BTU
|
10050
|
|
Suggested Pump Size
|
395-1050 GPH
|
